Standard Bed for Long Term Care

Standard Drive Bed for Long Term Care

Features:

450 lbs. weight capacity,Resident Weight 425 lbs

Best in class heightrange 7.8"to 30''

Integrated 76"and 80" length extension

Eight (8) Function Handheld Pendant Controlincludes Auto Contour

3Dc Motors keeps bedlevel with true vertical lift

Four sealed bearingsfor smooth/quiet ifting

Eight 3" Heavy Duty casters roll at anyheight,4locking,2 caster guide locks

Fixed wall bumper

Options:

Assist Rails, Assist Bars

Bed ends,two styles and three wood grain laminate colors

Height-Low Position:198mm

Height-High Position:760mm

Weight Capacity:450lbs

Bed Dimensions:1955×912×198mm

Motors:

3 DC Motors, The overalliting motor

loading 8000N, the back motor

loading 5000N, and the leg motor

loading 3500N,Input Voltage:100-240VAC,50/60 Hz

Deck Style:Steel pipe welding

Functions:Bed lifting, back plate lifting,leg plate lifting

Comfort Chair:Head deck lifting angle 60°

Leg/Foot Lift:Maximum hip-knee angle 30

Warranty:10 Years on Frame,15 Years on Welds,2 Years on Electrical

Caster Base:3 inch casters,2 head casters with brake,and 2 without brakes.With directional limit,2 foot casters with brakes and without brakes.
