3 Crank Manual Hospital Bed

Three-cranks Manual Hospital Bed

Function:
Back-rest tilting is 0~80º. Knee-rest tilting is 0~35º. Height adjustment is 460~740 mm.

Material:
Detachable ABS bed board,cold-rolled steel bed plate,self-protected crank system.


Standard accessory:
Aluminum alloy side rails,central lock system


Optional:
Two sectional IV pole,mattress,overbed table

A 3-crank manual hospital bed is a manually operated hospital bed that uses three separate hand cranks to adjust the patient's position, offering control over the backrest angle, the knee/leg section, and the overall height of the bed. This manual design provides economical patient comfort and caregiver assistance without relying on electricity, allowing for versatile positioning for comfort, clinical needs, and ease of patient transfer.

Functions and Operation

Each crank controls a specific function:

Backrest Adjustment: One crank is used to raise or lower the patient's back.

Leg Section Adjustment: Another crank controls the positioning of the patient's legs.

Height Adjustment: The third crank adjusts the overall height of the bed.

Benefits

Manual Control:

Allows caregivers to precisely adjust the bed to meet patient comfort and clinical needs.

Economical Solution:

Provides the comfort and features of more advanced beds but at a lower cost, as it doesn't require electricity.

Versatile Positioning:

Enables various patient positions, such as Fowler position (semi-sitting) for comfort or treatment.

Caregiver Support:

The height adjustment function makes it easier for caregivers to provide care and assist patients with transfers.

To use a 3-crank manual hospital bed, locate the three cranks at the foot of the bed: one for the head elevation, one for the foot (or knee) elevation, and one for the overall bed height. Turn the corresponding crank clockwise to raise that section of the bed and counter-clockwise to lower it. Store the crank at the foot of the bed when not in use.

Step-by-Step Operation

1. Locate the Cranks:

Find the three hand cranks located at the foot of the bed, underneath the frame.

2. Identify the Function:

Each crank controls a different movement:

Head Crank: Adjusts the angle of the backrest.

Foot (Knee) Crank: Adjusts the angle of the leg section.

Height Crank: Raises and lowers the entire bed vertically.

3. Insert the Crank:

Insert the notched end of the crank into the appropriate connection to begin making adjustments.

4. Raise or Lower:

To Raise: Turn the desired crank clockwise.

To Lower: Turn the desired crank counter-clockwise.

5. Store the Crank:

Once adjustments are complete, detach the crank and store it in its designated bracket at the foot of the bed.

Tips for Usage

Patient Comfort:

The different crank functions allow for various patient positions to enhance comfort and meet clinical needs.

Emergency Use:

These manual cranks can be used during a power outage to adjust the bed's position.

Varying Angles:

The back section typically adjusts from 0 to 75 degrees, while the foot section adjusts from 0 to 40 degrees.
